RAMRADE Rock Breakers

Rock breakers are built to withstand the toughest jobs and extreme conditions. These rock breakers incorporate excellent hydraulic systems, with high frequency and impact energy. The RAMRADE Breakers are designed for longer service life and reduced maintenance costs to empower breakthrough, proving itself in countless projects around Australia.

  • Size range suit up to 60 tonne excavators
  • Designed for extreme conditions
  • Noise reduction technology
  • Optional auto-greaser available
  • Fully shock absorbed
Facebook

About

RAMRADE Rock Breakers

Our Rock breakers are built with high strength steel to withstand the toughest jobs and extreme conditions. These rock breakers incorporate excellent hydraulics with high frequency and impact energy. With great features such as noise reduction technology, large monobloc housing, and super shock absorber elements. The RAMRADE Rock Breakers is an industry-leading brand. They ensure a profitable investment that pays for itself over and over again.

RAMRADE Rock Breakers suit a wide range of excavators from 1.7 to 50 tonne. Also suits a wide range of popular excavator brands such as: Hitachi, Kobelco, and Kubota.



About RAMRADE Attachments

RAMRADE Attachments is a world-class supplier of high-quality attachments to suit your excavator, skid steer, and other earthmoving equipment. They are manufactured to exceed rigorous global standards, and utilizing the most advanced technology. What’s more, these attachments are extensively field and factory tested to produce an outstanding range that consistently delivers. Browse the RAMRADE range

All attachments come with the necessary pins, bolts, tools, washers, gauges, and hoses for D.I.Y setup and maintenance. Owners can be confident in their ability to complete their jobs on time backed by efficient attachments!

For all your construction equipment needs, visit the RAM Equipment website for more details.

Specs

Additional information

Brands

RAMRADE Attachments

100 Series

Pick-up Dimensions: 85-95-30 mm Excavator Weight: 0.5 – 1.5 tonne Weight: 100 kg Required Oil Flow Range: 13 – 25 Lpm Operating Pressure: 75 -100 Bar Impact Range: 800 – 1,200 bpm Chisel Diameter: 40 mm

200 Series

Pick-up Dimensions: 85-95-30 mm Excavator Weight: 1.2 – 4 tonnes Weight: 200 kg Required Oil Flow Range: 20 – 30 Lpm Operating Pressure: 80-110 Bar Impact Range: 600 – 1000 Bpm Chisel Diameter: 45 mm

300 Series

Pick-up Dimensions: 180-145-45 Excavator Weight: 3- 5 tonnes Weight: 250kg Required Oil Flow Range: 25 – 40 Lpm Operating Pressure: 90 -120 Bar Impact Range: 550 – 950 Bpm Chisel Diameter: 53 mm

400 Series

Pick-up Dimensions: 245-170-45 Excavator Weight: 3.5 – 7 tonnes Weight: 380 kg Required Oil Flow Range: 30 – 45 Lpm Operating Pressure: 95 – 130Bar Impact Range: 500 – 900 Bpm Chisel Diameter: 68 mm

430 Series

Pick-up Dimensions: 300-200-50 mm Excavator Weight: 5 – 9 tonnes Weight: 500 kg Required Oil Flow Range: 40 – 80 Lpm Operating Pressure: 100 – 130 Bar Impact Range: 450 – 950 Bpm Chisel Diameter: 75 mm

450 Series

Pick-up Dimensions: 375-270-65 mm Carrier Weight: 7-12 tonnes Required Oil Flow Range: 45-85 Lpm Operating Pressure: 130 -150 Bar Impact Range: 400 – 800 Bpm Chisel Diameter: 85 mm

500 Series

Pick-up Dimensions: 375-270-65 mm Carrier Weight: 10 – 14 tonnes Required Oil Flow Range: 80 – 100 Lpm Operating Pressure: 150 – 170 Bar Impact Range: 450 – 700 Bpm Chisel Diameter: 100 mm

600 Series

Pick-up Dimensions: 445-348-70/80 mm Carrier Weight: 13 – 18 tonnes Required Oil Flow Range: 90 – 120 Lpm Operating Pressure: 150 – 170 Bar Impact Range: 400 – 800 Bpm Chisel Diameter: 120 mm Price: POA

700 Series

Pick-up Dimensions: 460-350-80 mm Carrier Weight: 18 – 26 tonnes Required Oil Flow Range: 125 – 150 Lpm Operating Pressure: 160 -180 Bar Impact Range: 400 – 800 Bpm Chisel Diameter: 135 mm

800 Series

Pick-up Dimensions: 460-350-80 mm Carrier Weight: 18 – 28 tonnes Required Oil Flow Range: 160-190 Lpm Operating Pressure: 160 – 180 Bar Impact Range: 350 – 750 Bpm Chisel Diameter: 140 mm

1000 Series

Pick-up Dimensions: 460-350-90/ 585-420-100 mm Carrier Weight: 28 – 35 tonnes Required Oil Flow Range: 160 – 190 Lpm Operating Pressure: 160 – 180 Bar Impact Range: 360 – 700 Bpm Chisel Diameter: 150 mm

1200 Series

Pick-up Dimensions: 475-420-90/585-420-100 mm Carrier Weight: 30 – 40 tonnes Required Oil Flow Range: 190 – 250 Lpm Operating Pressure: 160 – 180 Bar Impact Range: 210 – 450 Bpm Chisel Diameter: 155 mm

1300 Series

Pick-up Dimensions: 475-420-90/585-420-100 mm Carrier Weight: 33 – 48 tonnes Required Oil Flow Range: 200 – 260 Lpm Operating Pressure: 160 – 180 Bar Impact Range: 210 – 450 Bpm Chisel Diameter: 160 mm Price: POA

1500 Series

Pick-up Dimensions: 375-270-65 mm Carrier Weight: 40 – 60 tonnes Required Oil Flow Range: 220 – 310 Lpm Operating Pressure: 160 – 180 Bar Impact Range: 210 – 450 Bpm Chisel Diameter: 175 mm
